Audison Prima 2-Way 6"x9" Coaxial Speakers
Regular price
$439.99 CAD
Regular price
Sale price
$439.99 CAD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
The APX 690 features an exclusive 40 mm horn loading dome tweeter that contributes to maximize efficiency up to 96dB SPL and an acoustics lens specifically designed and applied to the tweeter to increase dispersion in the high frequency range. To strengthen the emission of very high frequency ranges otherwise affected by off-axis positioning compared to the listening point, the APX 690 featuring a supertweeter.
Technical Specs LF
| Woofer Size | 690 mm |
| Impedance | 4 Ohm |
| Power Handling - Peak | 300 W |
| Power Handling - Continuous | 100 W |
| Elliptical Size | 6 x 9 |
| Sensitivity | 96 dB |
| Frequency Response | 40 - 23k |
| Voice Coil Diameter | 25 mm (0.79 in) |
| Magnet Size | 90 x 32 x 15 |
| Xmax | 3.5 mm (0.98 in) |
Technical Specs HF
| Tweeter Size | 40 mm (1.57 in) |
| Voice Coil Diameter | 20 mm (0.79 in) |
| Super Tweeter Size | 15 |
Electric-acoustic Specs
| Re | 3.2 Ohm |
| Fs | 60 Hz |
| Mms | 16.6 g (0.59 oz) |
| Cms | 0.5 |
| Bl | 5.3 |
| Qms | 6.7 |
| Qes | 0,7 |
| Qts | 0.6 |
| Vas | 36 l (1.27 ft) |
| LE | 0.2 mH |
General
| Weight | 1.225 kg |
| Elliptical B1 | 222 mm |
| Elliptical B2 | 151 mm |
| Elliptical Dimension A1 | 238 mm |
| Elliptical Dimension A2 | 162 mm |
Dimensions
 |
|
| Dimension A1 | 238 mm |
| Dimension A2 | 162 mm |
| Dimension C | 96 mm (3.78 in) |
| Dimension D | 81 mm (3.19 in) |
| Dimension F | 25 |
| Dimension B1 | 222 mm |
| Dimension B2 | 151 mm |
| Dimension E1 | 276 mm |
| Dimension E2 | 202 mm |
