DB Drive Euphoria 15" EWX Blackout Edition DVC Subwoofer

Euphoria EWXB15D4 15" EWX Blackout Edition DVC Subwoofer

When it comes to high-performance car audio, few names command as much respect as Euphoria. Among their impressive lineup, the Euphoria EWXB15D4 15" EWX Blackout Edition DVC Subwoofer stands out as a powerhouse designed for audiophiles who crave deep, impactful bass. If you're in the market for a subwoofer that delivers both in terms of power and precision, this model might just be what you need.

The Powerhouse Behind the Bass

At the heart of the Euphoria EWXB15D4 is its robust construction and high power handling capabilities. With a dynamic power handling capacity of 2500 watts and a nominal power handling of 1000 watts, this subwoofer is built to handle intense audio signals without breaking a sweat. The dual 4-ohm voice coils offer flexibility in system configuration, allowing you to tailor your setup for optimal performance.

Engineered for Excellence

What sets the EWXB15D4 apart from the competition is its exceptional design and construction. This subwoofer features a 3" high-temperature voice coil that ensures reliable performance even under extreme conditions. This is crucial for maintaining sound clarity and preventing distortion at high volumes.

The 145 oz. ceramic ferrite magnet provides the necessary power to drive the voice coils, delivering a powerful magnetic field for enhanced bass response. Complementing this is the use of high-grade low-carbon steel on both the top and bottom plates, which not only reinforces the subwoofer’s structural integrity but also minimizes unwanted vibrations.

Designed for Superior SPL Performance

The Euphoria EWXB15D4 excels in SPL (Sound Pressure Level) performance. This is largely thanks to its high excursion spider and 1.5" high-roll foam surround. These features work together to allow the subwoofer’s cone to move more freely, which translates to deeper bass and greater overall impact. The high excursion spider is particularly notable for its ability to handle large amounts of energy, making it perfect for high-power audio systems.

User-Friendly Features

Ease of installation and use are crucial considerations for any audio component. The EWXB15D4 addresses these needs with large gauge push-button speaker terminals, which simplify the process of connecting your subwoofer to your amplifier. This feature ensures a secure connection and reduces the risk of signal loss.

Specifications That Speak Volumes

Let’s break down the key specs of the Euphoria EWXB15D4:

• Structure: 15" (38cm) Woofer
• Dynamic Power Handling: 2500 Watts
• Nominal Power Handling: 1000 Watts
• Impedance: Dual 4 Ohm Voice Coil

The subwoofer's dimensions are:

• Outside Diameter: 15.55" (395mm)
• Cutout Diameter: 14.06" (357mm)
• Mounting Depth: 7.4" (188mm)
