FOCAL FLAX SERIES 10 INCH SUBWOOFER
Couldn't load pickup availability
P25F is a 25cm (10″) subwoofer designed for a 18,4-liter- closed cabinet or a 25-liter- bass-reflex one. It is equipped with a very rigid Flax cone of 320 gr/m² which guarantees deep, powerful and linear bass. Its power is 300 Watts RMS and its frequency response goes from 33 to 500Hz. P25F Flax subwoofer represent a good compromise between bass pleasure and cabinet volume. The reference in the bass world!
The three Flax subwoofers consist of straightforward 4-Ohm voice coils which are perfectly suited for small enclosures (closed or bass-reflex). Several innovations raise their performance to an even higher level. Each model of subwoofer has a dual magnet, offering improved linearity and ensuring optimal magnetic power delivered to the voice coil, which features a new cooling system. Glass fibre has been used for the mounting of the voice coil, making it more robust while protecting the cone from the heat emitted. Last but not least, the new fixings connecting the cone to the voice coil and the spider to the basket improve reliability for extreme use (very high excursion).
Product Features
- "Dual Magnet" for More power
- FLAX® technology for an exclusive cone
- High rigidity for deep and controlled bass
- Compact size for sealed or ported enclosure
- High excursion
Specifications
- Woofer: 10" (250mm)
- Voice-coil: 2" (50mm)
- Voice-coil hight: 13/8" (35mm)
- Magnet: 5-11/16 (145mm)
- Max. power: 600 Watts
- Nominal power: 300 Watts RMS
- Sensitivity (2.83V/1m): 85dB
- Impedance: 4 Ohms
- Frequency response: 33Hz - 500Hz
- Mounting Depth: 5.1/2"
- Cutout: 9.20"
- Magnet Diameter: 5.71"
- Recommended Sealed Enclosure: 0.35 - 0.88 cu ft.
- Recommended Ported Enclosure: 0.88 - 1.23 cu ft
