X 165 Hertz Uno Series 6-1/2" 2-way car speaker
Couldn't load pickup availability
The 6.5” two way coaxials are available X 165 features a special designed tweeter faceplate optimized for exceptional off-axis performance to ensure a linear frequency response when installed in a factory replacement setup. The pressed-paper cone treated with water-repellent along with the foam surround provide a very high SPL and extended low frequency response, to obtain a rich sound even when driven by the OEM head unit.
The 25 mm(1ˈ) woofer voice coil driven by a high-flux density ferrite magnet offers a highly dynamic power handlingfor a powerful undistorted sound. The easy-to-install DIN size basket, protected by an abrasion-resistant dust paint, makes the factory speakers replacement a snap
1. Neodymium tweeter with PEI dome, for a brilliant reproduction of high frequencies and compactness.
2. Tweeter faceplate optimized for exceptional off-axis performance.
3. High stiffness metallic-grey finish pressed-paper cone with water-repellent treatment.
4. Foam surround combining high sensitivity and deep bass response.
5. Pure copper 25mm (1 in.) voice coil woofer for high dynamic power handling.
6. High flux density 80mm (3.15 in.) ferrite magnet for a powerful undistorted sound.
7. Easy-to-install DIN size basket protected by abrasion-resistant dust paint.
| Component | Coaxials |
| Size mm (in.) | 165 (6.5) |
| Power Handling - Continuous W | 55 |
| Power Handling - Peak W | 220 |
| Impedance Ohm | 4 |
| Tweeter diaphragm mm (in.) | 24 (0.9) |
| Woofer Voice Coil Ø mm (in.) | 25 (1) |
| Tweeter Voice Coil Ø mm (in.) | 14 (0.55) |
| Frequency Response Hz | 60 ÷ 21k |
| Woofer Magnet size D x d x h mm (in.) | 80 x 40 x 15 (3.15 x 1.57 x 0.59) |
| Tweeter Magnet size D x h mm (in.) | 13 x 1,5 (0.51 x 0.06) |
| Weight of one speaker kg (lb.) | 0,73 (1.61) |
| Woofer Magnet | High density flux ferrite |
| Tweeter Magnet | Neodymium |
| Cone | Water-repellent pressed paper |
| Dome | PEI |
| Xmech mm (in.) | ±3,5 (0.14) |
| A | 164,6 mm | 6.48 in. |
| B | 144 mm | 5.67 in. |
| C | 69 mm | 2.72 in. |
| D | 63 mm | 2.48 in. |
